  제  목 : SK-ECM 600

SPECIFICATION
MODEL SK-ECM 600
Cutting Capacity 200A ~ 600A
Loading Capacity 600KG
Chuck Clamping Method Manual By Handle
Motor STEEL 0.2 kw
SUS 0.4 kw
Chuck
Tilting
Method

Worm Reducer By Geared Motor

Angle

0 ~ 90°

Speed

1.5 ~ 5°/sec

Control Manual
Table Rotation
(Cutting)
Method

Worm Reducer By Geared Motor

Angle

±360°

Speed MAX. 32mm/sec
Control Manual
Measurenment Length 2500mm
Height 3600mm
Width 1400mm
Weight 2400kg
