HOME / Products / ELBOW CUTTING
SK-ECM 600
SPECIFICATION
MODEL
SK-ECM 600
Cutting Capacity
200A ~ 600A
Loading Capacity
600KG
Chuck Clamping Method
Manual By Handle
Motor
STEEL
0.2 kw
SUS
0.4 kw
Chuck
Tilting
Method
Worm Reducer By Geared Motor
Angle
0 ~ 90¡Æ
Speed
1.5 ~ 5¡Æ/sec
Control
Manual
Table Rotation
(Cutting)
Method
Worm Reducer By Geared Motor
Angle
¡¾360¡Æ
Speed
MAX. 32mm/sec
Control
Manual
Measurenment
Length
2500mm
Height
3600mm
Width
1400mm
Weight
2400kg
