» HOME / Products / TURNING ROLL




50~80TON

SPECIFICATION
▶ SPECIFICATION (50TON)
MODEL SK-TR 50

NOTE

LOADING C/P MAX 50,000KG

TURNING C/P 50,000KG

WELDING SPEED 0.27~1.65RPM

DC MOTOR CONTROL

TANK DIAMETER RANGE

Ø400~Ø5000MM

ROLL SIZE

Ø400 X 200W

ELECTRIC SOURCE

220V, 60Hz 3Ø

* The motor of Roll space control is optional for turning roll 50 tons.

▶ SPECIFICATION (80TON)
MODEL SK-TR 80

NOTE

LOADING C/P MAX 80,000KG

TURNING C/P 80,000KG

WELDING SPEED 0.27~1.75RPM

DC MOTOR CONTROL

TANK DIAMETER RANGE

Ø500~Ø7000MM

ROLL SIZE

Ø420 X 220W

ELECTRIC SOURCE

220V, 60Hz 3Ø
