[CHAIN_TYPE] SK-ROT 600

SPECIFICATION
MODEL SK-ROT 600 NOTE
LOAD PIPE 50A~600A -
C/P 2000kg -
ROLL SIZE ø 150 x 210L
-
TURNING SPEED 0~1300 mm/min
Inverter Regulation
TILTING ANGLE ±45˚
-
CONTROL SYSTEM MAIN P/L & Emergency S/W
-
FOOT S/W
TURNING ON/OFF
Safety TILTING Safety Pin -
TILTING Protection of Decelerator In Frame Decelerator Shaft Fixation
(BUSH TYPE)
-
TURNING ROLL B.R.G B.R.G Cover Assembly
(Body Protection from Foreign)
-
