SPECIFICATION

MODEL		SK-BD 150
MAX. TUBE DIAMETER/THK		ø 89.1 ~ 165.2/11t
EFFECTIVE TUBE LENGTH		6000 mm
BENDING	ROTATE	190˚
	SPEED	7.0˚ / sec
	CENTER	F.L + 1368 mm
	RADIUS	MIN : 2.5D, MAX : 3D
	FORMER	1-STEP
PRESSURE DIE BOOSTER		HYDRAULIC
HYDRAULIC PUMP		22 kw
AMOUNT HYDRAULIC OIL		700 LITER
CONTROL		1 CYCLE AUTO (SEMI AUTO)
TOTAL ELECTRIC POWER		25 kw
MACHINE	LENGTH	8200 mm
	HEIGHT	1570 mm
	WIDTH	2785 mm
	WEIGHT	11000 kg
